M Series Multiservice Edge Router

Blank plate for CB on T-series

Control Board, Blank

Control Board, Spare

M120 Control Board, Redundant

Compact Flash Upgrade Kit for RE-A-2000,RE-A-1000 and RE-S-2000 and RE-S-1300

M120 CFPC Blank Panel, Spare

M10i Chassis with Installed Midplane Spare (With Craft Interface)

M7i Chassis with Installed Midplane Spare (With Craft Interface), 1 built-in GE port.

Connector Interface Panel ,Spare, M320

Craft Interface Panel , Spare, M320

Fan Tray Blank Panel Spare for M10i

M7i Fan Tray Spare

M120 Forwarding Engine Board, Blank

Redundant M10i, M71 Forwarding Engine Board with 256MB DRAM

M10i Forwarding Engine Board with 128MB DRAM

M10i Enhanced Forwarding Engine Board, Redundant

Redundant M10i Forwarding Engine Board with 128MB DRAM

M120 Forwarding Engine Board

M7i Forwarding engine with 256MB DRAM - Spare option with built-in Adaptive Services Module

M7i Enhanced Forwarding Engine Board

M7i Enhanced Forwarding Engine Board with built-in Adaptive Services Module, Spare

M7i Enhanced Forwarding Engine Board with built-in Multi Services Module

M7i Forwarding engine - Spare option with built-in Adaptive Services Module

Front Fan Tray, Spare, M320

Filter Kit, Spare, M120

Chassis Manager for M10i

IPv6 Support on JUNOS

Logical Router Support for JUNOS

Promotional bundle consisting of M10iBASE-AC, PE-4GE-TYPE1-SFP-IQ2E and PE-MS-100-1

M10i Base Unit: 8 PIC slot chassis, cooling, midplane, 2 AC power supplies, 1 Forwarding Engine, 1 Routing Engine, 1 Fan Tray, JUNOS and two chassis managers. Optional flash media kit sold separately.

M10i Base Unit: 8 PIC slot chassis, cooling, midplane, 2 AC power supplies, 1 Enhanced Forwarding Engine, 1 RE-B-1800X1-4G, 1 Fan Tray, JUNOS-WW and two chassis managers. Optional flash media kit sold separately. Power cords sold separately.

M10i Base Unit: 8 PIC slot chassis, cooling, midplane, 2 DC power supplies, 1 Enhanced Forwarding Engine, 1 RE-B-1800X1-4G, 1 Fan Tray, JUNOS-WW and two chassis managers. Optional flash media kit sold separately. Power cords sold separately.

M120 Line Card Chassis: 4+2 slot chassis with cooling system, Midplane, 1 Routing Engine, 1 Control Board, and 1 AC Power Entry Module

M320 Base Unit includes Control Board, 4 Switch Interconnect Boards, 1 Routing engine, and 4 Power Entry Modules *SEE NOTES

M320 DC Base Unit includes Control Board, 4 Switch Interconnect Boards, 1 Routing engine, and 4 DC Power Entry Modules *SEE NOTES

M320 AC Base includes Control Board, 2 Switch Interconnect Boards, 1 Routing engine, and 2 AC Power Entry Modules *SEE NOTES

Special promotional package consisting of one M7iBASE-AC-1GE and one PE-1GE-SFP (optics sold separately). The M7iBASE-AC-1GE is an M7i Base Unit: 4 PIC slot chassis, 1 built-in Gigabit Ethernet Port (optics sold separately), cooling, midplane, 1 AC power

Promotional bundle consisting of M7iBASE-DC-1GE and PE-4GE-TYPE1-SFP-IQ2E

M7i Base Unit: 4 PIC slot chassis, 2 built-in Fast Ethernet Ports (RJ Connectors), cooling, midplane, 1 AC power supply, JUNOS, 1 Forwarding Engine, 1 Routing Engine. Optional flash media kit sold separately.

M7i Base Unit: 4 PIC slot chassis, 2 built-in Fast Ethernet Ports (RJ Connectors), cooling, midplane, 1 DC power supply, JUNOS, 1 Forwarding Engine, 1 Routing Engine. Optional flash media kit sold separately.

M7i Base Unit: 4 PIC slot chassis, 1 built-in Gigabit Ethernet Port (optics sold separately), cooling, midplane, 1 AC power supply, JUNOS-WW, 1 Enhanced Forwarding Engine, 1 RE-B-1800X1-4G. Optional flash media kit sold separately. Power cords sold separately.

M7i Base Unit: 4 PIC slot chassis, 1 built-in Gigabit Ethernet Port (optics sold separately), cooling, midplane, 1 AC power supply, JUNOS, 1 Enhanced Forwarding Engine, 1 Routing Engine 400Mhz. Optional flash media kit sold separately.

M7i Base Unit: 4 PIC slot chassis, 1 built-in Gigabit Ethernet Port (optics sold separately), cooling, midplane, 1 DC power supply, JUNOS-WW, 1 Enhanced Forwarding Engine, 1 RE-B-1800X1-4G. Optional flash media kit sold separately. Power cords sold separately.

M7i Base Unit: 4 PIC slot chassis, 1 built-in Gigabit Ethernet Port (optics sold separately), cooling, midplane, 1 DC power supply, JUNOS, 1 Enhanced Forwarding Engine, 1 Routing Engine 400Mhz. Optional flash media kit sold separately.

Optional M10i,M7i Forwarding Engine Board (FEB) Memory Upgrade: 256 MB DRAM Module

Optional RE Memory Upgrade: 256 MB DRAM Module (1 x 256)

10 Port Channelized E1/T1 (down to DS0) Enhanced IQ PIC, RJ48 Connector

12-port 10,100 TX Ethernet PIC. I Includes 3-meter VHDCI to RJ21 Ethernet Breakout cable. Connects to RJ21 to RJ45 patch panel and services (12) 10,100 Ethernet ports. Configured for MDI pinout.

12-Port Discrete T1/E1 (Telco connector). Does not ship with cables or patch panel. Recommended cable and patch panel vendor is Superior Modular Products (SMP). See notes column for SMP model numbers.

1-port Channelized OC12 / Channelized STM4 (down to DS0) Enhanced IQ PIC, (Requires a pluggable SFP Optics Module - See Interface Accessories section)

1-Port Channelized STM1 to DS0 IQ PIC, SM, IR

1-Port Gigabit Ethernet IQ PIC (Uses SFP Optics Module - See Interface Accessories section)

1-port OC-12,STM4 ATM2 IQ PIC, Single mode, IR (With diff. Serv)

1-port Non-Channelized OC12 / Non-Channelized STM4 Enhanced IQ PIC, (Requires a pluggable SFP Optics Module - See Interface Accessories section)

2-port Channelized OC3 / Channelized STM1 (down to DS0) Enhanced IQ PIC, (Requires a pluggable SFP Optics Module - See Interface Accessories section)

2 Port EIA-530 PIC (DB-25 Connector)

2-port OC-3,STM1 ATM2 IQ PIC, Single mode, IR (With diff. Serv)

4-port Channelized DS3 / Non-Channelized E3 (down to DS0) Enhanced IQ PIC, 75 ohm BNC

4-Port Channelized OC3/STM1 (down to T1/E1) Circuit Emulation PIC, SFP Optics sold separately.Requires pluggable SFP Optics Modules. SFP-OC3-IR or SFP-OC3-LR or SFP-OC3-SR; See Interface Accessories section

4-port Non-Channelized DS3 / Non-Channelized E3 Enhanced IQ PIC, 75 ohm BNC

4-port E1 PIC (120-ohm RJ48 connectors) with PIC ejector

4-port Fast Ethernet PIC, TX interface, RJ45 connector. with PIC ejector

4-Port Type 1 Gigabit Ethernet Enhanced IQ2 PIC

4-port Non-Channelized OC3 / Non-Channelized STM1 Enhanced IQ PIC, (Requires a pluggable SFP Optics Module - See Interface Accessories section)

8-port Fast Ethernet PIC, FX interface, MT-RJ connector, MMF. with PIC ejector

Bundle of PE-MS-100-1 and S-LSSL-4 for L2 services only

M10i shipping container spare

Shipping Container, Spare, M320

M10i,M7i Power Supply Blank Panel Spare

M320 Isolated DC Power Supply, Base Unit

M320 Isolated DC Power Supply, Spare

AC Power Entry Module, Redundant (for M320BASE-AC-EC only)

DC Power Entry Module, Base Bundle (for M320BASE, M320BASE-EC only)

DC Power Entry Module, Spare

M10i,M7i AC Redundant Power Supply Option (ordered with base unit) (Note: AC power cords are sold separately)

M7i,M10i DC Power Supply (ordered with base unit)

M10i,M7i DC Power Supply Spare

M120 AC Power Entry Module, Spare

M120 DC Power Entry Module, Spare

RE-400 for M10i, M7i with 768 MB Mem redundant

RE-400 for M10i, M7i with 768 MB Mem WW

Routing engine with 1000MHz CPU and 2GB memory, Redundant

Routing engine with 1000MHz CPU and 2GB memory, Spare (JunOS Worldwide)

Routing Engine - Dual Core 1800Ghz with 16G Memory, Spare

Routing Engine - Dual Core 1800Ghz with 16G Memory, Worldwide version

Routing Engine - Dual Core 1800Ghz with 8G Memory, Spare

Routing Engine - Dual Core 1800Ghz with 8G Memory, Worldwide version

Routing engine with 2000MHz processor and 4GB memory, Redundant

Routing engine with 2000MHz CPU and 4GB memory, Base Bundle

Routing Engine with 1.73GHz processor, 4GB DDR3 memory with ECC, 64 GB SSD and 4GB compact flash

Spare Routing Engine with 1.73GHz processor, 4GB DDR3 memory with ECC, 64 GB SSD and 4GB compact flash

RE Blank Cover, Spare

Compact Flash media upgrade for RE

M120 Rear Fantray, Spare

Chassis license for Application Traffic Optimization service, policy enforcement and application stats. This license includes S-AI and S-LDPF functionality, Includes 1 Year Signature Subscription License

Security Services license for AS and MS PIC

L2TP LNS license for 16K session for M120 on MS PIC

L2TP LNS license for 2K sessions on M7i,M10i and M120 AS PIC or Integrated Adaptive Services Module and MS PIC

L2TP LNS license Upgrade from 2K to 4K sessions for M7i,M10i and M120 AS PIC or Integrated Adaptive Services Module and MS PIC

L2TP LNS license Upgrade from 4K to 8K session_ for M7i, M10i and M120 AS for MS PIC

Link Services Software Ugrade License - from 255 to 1023 ML bundles per Chassis for MS PIC and MS DPC

Link Services Software License - up to 255 ML bundles per Chassis for AS PIC, MS PIC and MS DPC

Link Services Software License - up to 64 ML bundles per Chassis for AS PIC, MS PIC and MS DPC

Software License for Passive Monitoring Flow Monitor Application supporting 1M flows. Chassis based license for MS-PIC.

NAT,FW license on AS and MS PIC: Single-instance

Tunnel services software license for AS and MS PICs (chassis license)

Redundant Switch Interconnect Board
