QSFP Cables: 40G DAC and AOC

The main difference is speed and density. SFP (Small Form-factor Pluggable) supports speeds typically up to 10G and has a single channel. QSFP (Quad SFP) supports four channels, enabling speeds of 40G (4x10G) or higher. QSFP is physically wider to accommodate the extra channels, providing much higher bandwidth density for modern data center applications.

A QSFP transceiver is a compact, hot-pluggable module used in data communications. It converts electrical signals to optical signals (and vice-versa) to connect network devices over fiber optic cables. It plugs into a QSFP port on a switch or server. QSFP DAC and AOC cables have the transceivers integrated directly into the cable assembly, simplifying connections.

The key differences are data rate and physical form factor. SFP cables are designed for lower speeds like 1G or 10G, while QSFP cables are built for 40G and higher. A QSFP connector is wider than an SFP connector to house four data channels instead of one. They are not interchangeable, though breakout cables (e.g., QSFP+ to 4xSFP+) can be used to connect ports of different types.

To connect a 40G QSFP+ port to four 10G SFP+ ports, you need a QSFP+ to 4xSFP+ breakout cable. This can be a Direct Attach Copper (DAC) or Active Optical Cable (AOC). One end has a QSFP+ connector that plugs into the 40G port, and the other end splits into four separate cables, each with an SFP+ connector to plug into the 10G ports on other devices.

Direct Attach Copper (DAC) cables are a highly cost-effective and low-power solution for very short-range connections, typically up to 7 meters. They offer lower latency because they don't perform electrical-to-optical conversion. However, for longer distances, Active Optical Cables (AOC) are required as they are lighter, more flexible, and immune to electromagnetic interference.

Yes, when sourced from a reputable supplier. At Terabit Systems, every refurbished QSFP cable undergoes a rigorous 5-step quality assurance and testing process to ensure it meets or exceeds original manufacturer specifications. This allows us to provide reliable, high-performance hardware backed by a solid warranty, offering peace of mind along with significant cost savings.
